Packaged Drinking Water Plant
Kastino Machine is a leading manufacturer and exporter of fully automated Packaged Drinking Water Plants, delivering turnkey solutions tailored for consistent quality, hygiene, and efficiency. Our state-of-the-art water purification systems are built to meet global standards and offer unmatched performance across industrial, commercial, and municipal applications.
Water Purification Process Overview
Our plants follow a meticulous multi-stage purification process to produce crystal-clear, safe, and great-tasting drinking water:
1. Chlorination & Storage
Raw water is treated with Sodium Hypochlorite using a metering pump to disinfect and eliminate microbes. It is stored in tanks (20–50 m³) to allow proper contact time for disinfection.
2. Multi-Media Filtration
Using a high-capacity Multi-Media Filter, suspended solids and coarse impurities are removed.
3. Activated Carbon Filtration
Chlorinated water is passed through an Activated Carbon Filter to remove excess chlorine, color, odor, and organic matter.
4. Anti-Scalent Dosing & Micron Filtration
Anti-scalent solution is dosed to prevent membrane scaling.
Water passes through 10-micron bag filters and 5-micron cartridge filters to reduce SDI and protect the RO membrane.
5. SMBS Dosing
Sodium Metabisulfite (SMBS) is added to neutralize any remaining chlorine.
6. Reverse Osmosis (RO)
The core purification stage uses high-pressure RO membranes to remove up to 95–98% of dissolved salts and impurities.
7. Post-Treatment Adjustments
pH and TDS are adjusted.
Water is passed through a 0.2-micron cartridge filter and UV sterilizer.
8. Ozonation & Final Storage
Ozone gas is injected to ensure microbial safety. Treated water is stored in SS tanks ready for filling and packaging.
⚙️ Equipment Schedule
| Equipment | Description |
|---|---|
| Chlorine Dosing System | 50L HDPE tank with LMI metering pump |
| Raw Water Booster Pump | SS 304, Grundfos or equivalent |
| Sand Filter | SS-316 tank, Austrian control valves |
| Activated Carbon Filter | SS-316 tank, dual-media with control valves |
| Anti-Scalent Dosing System | 100L HDPE tank, LMI pump |
| 10 Micron Filter | SS housing, pressure gauge |
| 5 Micron Filter | SS housing with washable bags |
| Reverse Osmosis Unit | Fully automatic, Grundfos pump, membranes, TDS meter, control panel |
| SMBS Dosing System | 100L HDPE tank, LMI pump |
| SS Storage Tank | 2000L SS 304/316 hygienic tank |
| SS Booster Pump | With level interlocking and isolation valves |
| Micron Filters (0.2 µm) | Stainless steel housing |
| UV Sterilizer | SS housing, UV lamps with quartz jackets |
| Ozonation Unit | Corona discharge with repressurization pump, safety unit |
| Electrical Control Panel | Powder-coated with relays, TDS monitor, sensors |
| Wet Panel | Flow indicators, gauges, and control valves |
✅ Treated Water Quality
| Parameter | Result |
|---|---|
| Suspended Solids | Nil |
| Turbidity | Nil |
| pH | 7.0 – 7.5 |
| TDS | < 40 ppm |
| Total Hardness | < 30 ppm (as CaCO₃) |
| Bacteria/Coliform | Nil |
Custom mineral adjustment available based on application and source water.
Feed Water Requirements
Temperature: Max 40°C
Free Chlorine, Oil, Bacteria: Nil
Turbidity: < 1.0 NTU
Iron, Manganese: Nil
Scope of Exclusion
Civil works and foundation setup
Raw water storage tanks
Electrical and plumbing infrastructure
Testing chemicals and lab facilities
Why Choose Kastino?
🛠️ Expert Engineering: Proven systems built with premium components
🔒 Hygienic Construction: SS-304/316 material for water contact parts
🌐 Global Reach: Export-quality systems ready for international deployment
🔁 Automation Ready: Smart panels, sensors, and safety interlocks
📊 Customizable Solutions: Tailored to your water source and output needs
Contact Us Today
Launch your own Packaged Drinking Water Brand with Kastino’s complete water treatment plant solutions
